Ubiquiti USW-16-POE UniFi Switch 16 Port Gen2 802.3at PoE Gigabit Switch with SFP

฿14,570.00 (รวมภาษี)

฿13,616.82 (ไม่รวมภาษี)

รหัสสินค้า: USW-16-POE

มีสินค้าอยู่ 100

Product successfully added to the Quote List

Ubiquiti USW-16-POE

UniFi Switch 16 Port Gen2 802.3at PoE Gigabit Switch with SFP

Specifications :

Mechanical
Dimensions	442 x 200 x 44 mm (17.4 x 7.9 x 1.7″)
Weight	Without mounting brackets: 2.8 kg (6.2 lb) With mounting brackets: 2.9 kg (6.4 lb)
Enclosure material	SGCC steel
Hardware
Management interface	Ethernet In-Band
Networking interface	(16) GbE RJ45 ports (2) 1G SFP ports
PoE interface	(8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput	18 Gbps
Switching capacity	36 Gbps
Forwarding rate	26.78 Mpps
Power method	Universal input, 100—240V AC, 50/60 Hz
Power supply	AC/DC, internal, 60W
Supported voltage range	100—240V AC
Max. power consumption	18W (Excluding PoE output)
Total available PoE	42W
Max. PoE wattage per port by PSE	PoE+: 32W
Voltage range PoE mode	PoE: 44—57V PoE+: 50—57V
ESD/EMP protection	Air: ± 16kV, contact: ± 12kV
LCM display	(1) 1.3″ touchscreen
Button	Factory reset
Shock and vibration	ETSI300-019-1.4 Standard
Ambient operating temperature	-5 to 40° C (23 to 104° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Switching Features
Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	–
LEDs
System	Status
Ethernet	PoE Speed/link/activity
SFP	Link/activity
Application Requirements
UniFi Network	Version 7.2.94 and later
