HPE JL824A HPE 5140 48G POE+ 4SFP+ EI Sw (48x1G Base-T PoE+, 4xSFP+)

฿294,581.70 (รวมภาษี)
฿275,310.00 (ไม่รวมภาษี)

รหัสสินค้า: JL824A

มีสินค้าอยู่ 201

HPE JL824A

HPE FLEXNETWORK 5140 EI SWITCH SERIES



HPE FlexNetwork 5140 EI Switch Series delivers scalability, high availability, and low TCO at the access layer of medium and large enterprise campus networks. The series offers enterprise-class quality of service (QoS) and security, HPE IRF stacking, static Layer 3 routing and RIP, convenient fixed 10GbE uplink ports, PoE+, ACLs, and IPv6 and delivers energy savings with Energy Efficient Ethernet.

HPE FlexNetwork 5140 EI Switch Series delivers scalability, high availability, and low TCO at the access layer of medium and large enterprise campus networks. The series offers enterprise-class quality of service (QoS) and security, HPE IRF stacking, static Layer 3 routing and RIP, convenient fixed 10GbE uplink ports, PoE+, ACLs, and IPv6 and delivers energy savings with Energy Efficient Ethernet.



Features :

  • Gigabit Ethernet access switch with static Layer 3 routing, RIP, high density 10GbE uplinks, and PoE+ models for voice, video, and wireless
  • Supports HPE Intelligent Resilient Fabric (IRF) technology that enables plug-and-play device aggregation and link aggregation across multiple devices, enhancing network redundancy and resource utilization
  • Includes embedded network management capabilities at no additional cost with Smart Management Center (SmartMC)
  • Includes energy-saving green design features such as automatic switching of idle ports to energy-saving mode and powering down unused ports



Specifications :

Product HPE FlexNetwork 5140 48G PoE+ 4SFP+ (370W) EI Switch (JL824A )
I/O ports and slots 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP+ fixed 1000/10000 SFP+ ports
Additional ports and slots 1 RJ-45 serial console port
Dimensions 17.32(w) x 14.17(d) x 1.72(h) in (44 x 36 x 4.36 cm) (1U height)
Weight 17.64 lb (8 kg)
Memory and processor 512 MB SDRAM, 256 MB flash
Mounting and enclosure Mounts in an EIA standard 19-inch telco rack or equipment cabinet (Rack Mount Kit R8M91A sold separately)
Performance IPv6 Ready Certified
1000 Mb Latency < 5 µs
10 Gbps Latency < 3 µs
Throughput 131 Mpps
Routing/Switching capacity 176 Gbps
Routing table size 1024 entries
MAC address table size 16384 entries
Operating temperature 23°F to 113°F (-5°C to 45°C)
Operating relative humidity 10% to 90%, noncondensing
Non-operating/Storage temperature -40°F to 158°F (-40°C to 70°C)
Non-operating/Storage relative humidity 5% to 95%, noncondensing
Acoustic Low-speed fan: 43.5 dB, High-speed fan: 52.8 dB; ISO 7779
Frequency 50/60 Hz
Maximum heat dissipation 160/1671 BTU/hr (168.8/1762.91 kJ/hr), for AC power. For DC power min heat dissipation is 147 BTU/hr and 3037 BTU/hr max.
Voltage 100 – 240 VAC
-54 to -57 VDC
Current 10:00 AM
Maximum power rating 478 W
Idle power 47 W
PoE power 370 W PoE+
