Zyxel SURGEPRO-GE

Ethernet Surge Protector



Equipment relies solely on protective components and grounding to dissipate energy for fundamental protection. If the lightning surge is excessively strong, it could result in damage to the equipment. The Ethernet surge protector, SURGEPRO-GE, plays a crucial role in safeguarding commercial networking products. It shields them from power interference, ensures data security, and prolongs device’s lifespan, thereby sustaining uninterrupted business operations.



Features :

• Robust level of Line-Line, Line-Ground protections
• PoE Ethernet surge protector: compatible with Power-overEthernet IEEE 802.3af/at/bt
• Supports network speeds of 10 Mbps, 100 Mbps, and 1 Gbps for connections up to 100 meters
• Easy, and fast installation



Specifications :

Product Name: Ethernet Surge Protector

Interface Connections: 2 RJ-45 connectors

Data Line Protection: RJ-45 10/100/1000 Ethernet

IEEE 802.3af/at/bt Support: Yes (802.3bt 60 W supported)

Maximum Operating DC Voltage: 60 VDC

Maximum Discharge Current: 8 kA

Line to GND Protection Level: 20 kV (10/700 µs) / 10 kA (8/20 µs)

Line to Line Protection Level: 4 kV (10/700 µs)

Response Time: < 5 ns

Minimum Power Consumption: 1.62 watts

Physical Specifications:

• Dimensions (W x D x H): 40 x 120 x 25 mm / 1.57 x 4.72 x 0.98 in

• Weight: 121 g / 0.27 lb

Operating Conditions:

• Temperature: -40°C to 85°C / -40°F to 185°F

• Humidity: 10% to 90% (non-condensing)

Storage Conditions:

• Temperature: -40°C to 85°C / -40°F to 185°F

• Humidity: 10% to 90% (non-condensing)

Certifications: FCC (Class B), CE (Class B), IEC 61000-4-5, IEC 61643-21, ITU-T K.21
