Zyxel NXC5500

Wireless LAN Controller



Zyxel’s next generation WLAN controller, the NXC5500, is capable of extending networks flexibly and fulfilling different deploy requirements with excellent Access Point (AP) compatibility; and the NXC5500 can centralize WLAN management to reduce extra efforts. The NXC5500 is easy to use and scalable for hotels, education institutions, chain stores as well as small- to-medium-size enterprises to configure network solutions that meet their specific needs.



Benefits

Centralized management and provision

With demand for Internet connection of mobile devices growing rapidly, high scalability WLAN and centralized management become necessary for wireless device deployments. The Zyxel NXC5500 WLAN controller has great scalability to manage up to 1024 APs centrally. The NXC5500 utilizes CAPWAP protocol to minimize issues of Wi-Fi deployments that are new, or belong to extension programs on top of the existing networks.

Adaptive and resilient Wi-Fi deployments

The Zyxel NXC5500 features with ZyMesh to solve the complex cable deployments when extending Wi-Fi coverage, and provide high resilience Wi-Fi service with multiple route selections for each repeater APs. In the past, administrators had to assign a channel and MAC addresses in each AP while setting up a WDS link to extend Wi-Fi service; now they can make auto provision and manage easily.

WLAN optimization and enhanced RF management

All wireless networks face a major challenge: ensuring Wi-Fi clients get service levels they’d need. Therefore, there are several kinds of Wi-Fi clients exist on the network, and these users tend to make their own connectivity and roaming decisions. The NXC5500 can monitor the capabilities of each wireless client and steer the client to the best radio on the best AP by band select and signal threshold. Also, the NXC5500 can detect status of neighbor AP and adjust output power automatically to ensure a non-stop Wi-Fi service.

Secured wireless edge and access management

The NXC5500 features with diversified Wi-Fi security features and comprehensive access control to help enterprises and businesses address the wireless security issues that arise with BYOD.



Specifications :

NXC5500
Port Density
10/100/1000 Mbps LAN ports 6
USB Port 2
Performance
Throughput (Gbps) 6
Managed AP number (default/max.) 64/1024
WLAN Features
Wireless security (WPA/WPA2-PSK, Enterprise) Yes
Dynamic channel selection Yes
Wireless multicast setting Yes
AP load balancing Yes
AP planning and site-survey Yes (AP planning and coverage detection)
ZyMesh Licensed service
Band select Yes
Client signal threshold Yes
Auto healing Yes
Security Features
IEEE 802.1X Yes
IEEE 802.11w Yes*
Layer-2 isolation Yes
Web authentication Yes
Stateful firewall Yes
MAC filtering Yes
RADIUS authentication Yes
Microsoft AD authentication Yes
LDAP authentication Yes
Embedded RADIUS server Yes (4096 user)
Identity-based user security management Yes
Wireless intrusion detection Rogue AP detection and containment
Control and Provisioning
Managed AP discovery Broadcast/DHCP option/DNS/Manual
CAPWAP Yes
AP data forwarding mode Distributed (local bridge) and Centralized (data tunnel)
Management interface HTTP/HTTPS/Telnet/SSH/SNMP
Output power control Yes
Dynamic channel assignment Yes
Network
VLANs Yes
DHCP client Yes
DHCP relay, server Yes
NAT Yes
Static routing 256
Policy routing 1000
Access Control
MAC access control list Yes
MAC authentication Yes, internal and external RADIUS
Guest account generator Yes (2048 user)
Customizable web login portal Yes
QoS
WMM/power save Yes
DiffServ marking Yes
AP load balancing Yes
Management Features
CLI with SSH Yes
Web UI with SSL Yes
myZyXEL.com 2.0 Yes*
SNMP v1, v2c, v3
Multi-level administration roles Admin, guest operator
User/Application management
Authentication RADIUS/Microsoft AD/LDAP/Local
Local user database Yes (4096)
User/group policy Yes
Authentication by QR code Yes*
Captive portal Yes
External portal page Yes
Page upload Yes
Other
System diagnostic tool Yes
Certification
EMC
  • EMI and susceptibility (Class A)
  • FCC Part 15.107 and 15.109
  • CE EN55022, EN55024
  • ERP Lot 6
  • BSMI CNS13438
Safety
  • LVD EN60950-1:A12
  • BSMI  CNS14336
Power Requirement
Power supply 100~240VAC
Max. power consumption (watt) 138
Physical Specifications
Item Dimensions (WxDxH)(mm/in.) 438 x 302.7 x 44/17.24 x 11.92 x 1.73
Weight (kg/lb.) 4.750/10.47
Packing Dimensions (WxDxH)(mm/in.) 680 x 425 x 190/26.77 x 16.73 x 7.48
Weight (kg/lb.) 8.525/18.79
Included accessories
  • Ethernet cable
  • Console cable
  • Power cord
  • Rack mounting kit
Environmental Specifications
Operating Environment Temperature 0°C to 40°C/32°F to 104°F
Humidity 10% to 90% (non-condensing)
Storage Environment Temperature -30°C to 70°C/-22°F to 158°F
Humidity 10% to 90%
MTBF (hrs) 43,800
