Vertiv 14240257 Geist Rack basic PDU: 32A Rated, Hardwired, 20xC13 + 4xC19, Black, 0U

Vertiv 14240257 Geist Rack basic PDU: 32A Rated, Hardwired, 20xC13 + 4xC19, Black, 0U

฿10,000.00 (รวมภาษี)
฿9,345.79 (ไม่รวมภาษี)

รหัสสินค้า: 14240257

มีสินค้าอยู่ 100

Vertiv 14240257

Geist Rack basic PDU: 32A Rated, Hardwired, 20xC13 + 4xC19, Black, 0U



C1652 -Basic Standard, 32A, 230V, 7.3kW, Vertical, (20) IEC C13, (4) IEC C19, Breakered, 3m power cord Hardwired, Black Powder Coat



Benefits :

  • Reliable rack powerdistribution

  • Every unit is 100% tested for reliability and functionality

  • Simple and convenient configuration options for cord lengths and chassis colors

  • Standard three-year warranty, upgraded to five years with product registration



Features :

  • Available in vertical and horizontal rackmount form factors.

  • Flexibility to meet a broad range of requirements, with a variety of electrical and receptacle configurations available.

  • Simple and quick installation in all standard racks or cabinets with included mounting brackets.



Specifications :

Quantity Of Inputs 1
Voltage 230V
Current 32A
VA per Input (Load Capacity) 7.3kW (230V)
Frequency 50/60Hz
Over Current Protection (2) 16A Single Pole Magnetic Breakers
Switch Breaker/Switch Combination
Power Cable Length 3m
Plug Type 3 × 4mm² hardwire
Receptacle/Socket Type #1 IEC C13
└ Quantity 20
└ Quantity per Breaker 10
└ Maximum Output per Receptacle/Socket 10A
└ Voltage per Receptacle/Socket 230V
Receptacle/Socket Type #2 IEC C19
└ Quantity 4
└ Quantity per Breaker 2
└ Maximum Output per Receptacle/Socket 16A
└ Voltage per Receptacle/Socket 230V
Maximum Operating Temperature 45℃ / 113°F
Material / Finish Heavy Steel – Powder Coat Finish Black
Configuration 0U, Vertical
Toolless Mounting HW (Center to Center) 1560mm and 1645mm (Vertical mounting bracket included)
Product Warranty 5-year limited warranty (if registered within 120 days), otherwise 3 years
Certification / Agency Approvals CE, EN55032 & EN55024, IEC62368-1, RoHS
Chassis Dimensions (H×W×D) 1683mm × 51mm × 51mm
