1.3 GHz Dual-Core, ARM Cortex-A53

128 MB (1 Gbit) NAND

256 MB (2 Gbit) DDR3

2402 Mbps

574 Mbps

2T2R (2×2 MIMO) with an Extra Stream

2T2R (2×2 MIMO)

4× Fixed

5.3dBi

5.3dBi

• 5 GHz: 3× Internal

• 2.4 GHz: 2× Internal

True

Max: 220 m (722 ft)

Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.

Two wooden walls with thickness < 10 cm (4”)

One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”)

5

1× WAN port, the rest are LAN ports

• System

• Internet

• WPS

• 2.4 GHz Wi-Fi

• 5 GHz Wi-Fi

• WAN

• LAN

• WPS Button

• Reset Button

DC Jack

DC

12V 1A

Input: 100 ~ 240 V, 50/60 Hz AC

Output: 12V 1A DC

11.5w

4.2w

• Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)

• Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)

• Humidity: 10% ~ 90% non-condensing

• Storage Humidity: 5% ~ 95% non-condensing

• Desktop

• Wall-mount

173×123.8×33 mm

6.81×4.87×1.3 inches

329.4 g (11.62 oz.)
